HPC Fire Duel-Step Push Button Flame Sensing Outdoor Gas Fireplace Burner Kit

SKU: DBOF-PBFS-Config

Free Shipping!

Usually Ships in 14-28 Business Days

Price:

$888.25

view full details

Optional Accessories:

Product Features

Stainless Steel Construction - Powder-coated stainless steel burner and pan protects against rust to ensure a long lasting product

Push Button Ignition System - Easily light the unit with the push of a button

Sealed Control Box - Water resistant control box features stainless steel construction to hold up outdoors

H-Burner Design- H-burner design with elevated rear leg; Adjustable rea pan height for flame performance variability

Product Description

The HPC Fire Duel-Step Push Button Flame Sensing Outdoor Gas Fireplace Burner Kit combines premium design with quality construction for a superior outdoor fireplace burner kit. Featuring powder-coated black stainless steel construction in both burner and pan, this kit has been designed to withstand the test of time. The low-profile design of the included burner offers attractive aesthetics with any media, while standard burner ports offer improved flame performance. Both the burner and pan feature integrated weep holes to ensure proper water drainage to extend the life of the components as well as a NEMA-rated valve for weather protection. Burners and pans are also backed by a Limited Lifetime Warranty from HPC.

These burner kits feature the added convenience of a simple push button ignition to easily light the system. For added safety, these systems feature flame sensing technology to automatically stop gas flow in the event flames are extinguished.

⚠️ WARNING: This product can expose you to chemicals including LEAD AND LEAD COMPOUNDS, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov/.

Choose Product Options To See Full Specifications

What to Consider When Building a Gas Fire Pit:

Gas Supply - Before you begin designing your fire pit, first determine your gas supply

Both Natural Gas and Propane may be used - Supply Pressure and BTU ratings need to be regulated for both

For Natural Gas: Supply Pressure should be set between 3.5" - 7" Water Column

For Propane*: Supply Pressure should be set between 8" - 11" Water Column

*Do not use a burner rated for greater than 125,000 BTU with a 20-pound propane tank.

Fire Pit Burner - The shape and size of your fire pit burner can be choosed after determining your gas supply

Choose a burner kit based off of the inside dimension of your enclosure - the fire pit pan will be 6" larger than the burner to provide at least 3" between the edge of the burner and the inside edge of the pit

Fire Pit Pan - Included with all of HPC's preassembled fire pit kits

A pan can be flat or "bowl" style in order to accommodate your construction - it should be installed at least 3-4" below the top surface of your enclosure
The burner pan separates the air mixer from the burner in propane applications, but in all constructions it helps with water drainage and ventillation

Flange Extension - In many cases, the shut-off valve will be located inside the fire pit - if your enclosure walls are thicker than 3" it may be necessary to use a flange extension and a longer key

An external shut off valve is not required with this kit, but may be an option for added safety

Ventilation - For all fire pit burners, adequate ventilation is required

The recommended amount of ventilation is 36in² - or (2) 18in² vents on two opposing sides to create proper airflow

Installation Collars - Are designed to simplify the installation of a fire pit pan

Our flexible installation collars can bend for round enclosures and can be anchored in with concrete screws

Fire Media - Is the final step to finishing a gas fire pit

Both lava rock and fire glass may be used to complete your fire pit, the choice between the two is purely aesthetic
